Gear up for the ultimate fishing experience with the Garmin Echomap UHD2 95SV. Featuring the powerful GT-56TM transducer, this combo brings traditional, SideV, and ClearV sonar capabilities to your fingertips, making it easier than ever to track fish and underwater structures with Garmin’s vivid colour palette displays. Preloaded with Navionics+ charts for Australian and New Zealand waters, its the perfect tool for both navigation and fishing. The 9-inch touchscreen display with keyed-assist ensures seamless operation, even under harsh sunlight, while the multi-band GPS provides pinpoint accuracy. With built-in Wi-Fi, NMEA 2000 network integration, and support for LiveScope live-scanning sonar, this combo offers everything an angler needs. It also allows you to share sonar, waypoints, and routes wirelessly with other ECHOMAP UHD2 chartplotters. Upgrade your fishing game with Auto Guidance+ technology for smarter route planning and enjoy the convenience of the ActiveCaptain app for smart notifications and access to the Garmin QuickDraw Community. The Echomap UHD2 95SV is your ultimate tool for fishing mastery in Australian waters.
Dimensions: 26.4 x 16.6 x 8 cm
Display Size: 19.8 x 11.5 x 22.9 cm
Display Resolution: 1024 x 600 pixels
Display Type: WVGA, TN
Weight: 1.3 kg
Waterproof Rating: IPX7
Mounting Options: Bail or Flush
Input: Touchscreen with Keyed Assist
Data Cards: 1 micro SD, 32 GB max size
Waypoints: 5000
Track Points: 50000
Tracks: 50 saved tracks
Navigation Routes: 100
Built-In Receiver: Yes
Receiver: 10 Hz
GPS: Yes
Supports WAAS: Yes
Supports Multi-Band, Multi-Constellation GPS: Yes
Built-In Auto Guidance +: Yes (downloadable via ActiveCaptain app)
Garmin Navionics+ (Coastal and Inland): Yes
Tide Tables: Yes
ActiveCaptain Mobile App: Yes
Displays Sonar: Yes
Power Output: 500W
Traditional Sonar: Built-in (single channel CHIRP, 50/77/83/200 kHz, L, M, H CHIRP)
ClearVu Sonar: Built-in 260/455/800/1000/1200 kHz
SideVu Sonar: Built-in 260/455/800/1000/1200 kHz
Panoptix Sonar Compatibility: Yes
Livescope Sonar Compatibility: Yes
NMEA 2000 Ports: Yes
Bluetooth Pairing: Yes
ANT+ (Connectivity): Yes
Garmin WiFi Network (Local Connection): Yes
Garmin Marine Network Ports: 1
12-Pin Transducer Ports: 1
Power Input: 9 – 18 V DC
Typical Current Draw at 12V DC: 1.72 amp
Max Current Draw at 12V DC: 3.5 amp
Max Power Usage at 10V DC: 20.7 W
